16 Channels 75 Ohm BNC To 120 Ohm RJ45 E1 Impedance Balun Converter
Product Overview of 16 E1 Impedance Balun Converter
FC-BC16 E1 Impedance Converter Provide 1~24 channels G.703 75(BNC) to 120Ω(RJ45) Converter ,no need power;
Product Features of 16 E1 Impedance Balun Converter
Ø E1 75/120 Interface level conforms to the ITU-T G.703 level standard template;
Ø 75 and 120 ohm impedance two-way signal conversion, easy to use
Ø Without external power supply
Technical parameters of 16 E1 Impedance Balun Converter
Bit Rate | 2048±50ppm | |
Impedance | 75WNon Balance | 120W Balance |
The "mark" (pulse) nominal peak voltage | 2.37V | 3.0V |
"Empty" (no pulse) nominal peak voltage | 0±0.237V | 0±0.3V |
Nominal pulse width | 244ns | |
Pulse width at the midpoint of the positive and negative pulse amplitude ratio | 0.95~1.05 | |
Nominal pulse amplitude, pulse width ratio of positive and negative half | 0.95~1.05 | |
Model | FC-BC16 |
Functional Description | 16xE1 Impedance Converter Provide 16 channel G.703 75(BNC) to 120Ω(RJ45) Converter |
Port Description | 16*75ohm E1(BNC)+16*120 ohm E1(RJ45) |
Power | Not Need |
Dimension | 80(length) X 65(width) X26(height) mm |
Weight | 0.20Kg/Pcs(DeskTop Type) ; |
E1 Interface | E1 interface protocol: ITU-T G.703, |
Interface Rate: 2048Kbps±50ppm | |
Interface Code: HDB3; | |
Impedance: 75Ω (unbalance BNC), 120Ω (balance RJ45) | |
Working environment | Working temperature: -40°C ~ 80°C |
Working Humidity: 5%~95 % (no condensation) | |
Storage temperature: -40°C ~ 85°C | |
Storage Humidity: 5%~95 % (no condensation) | |
MTBF: >500,000 hours |
Networking Applications of 16 E1 Impedance Balun Converter
Fibreasy | OEM manufacturer |
Factory | Located in Hangzhou |
Special requirements | Customized |
Certifications | ISO9001, CE |
Payment | T/T, L/C, Wester Union, Paypal |
Shippment | DHL, Fedex, TNT, UPS, EMS |
Warranty | 3 years |
